ALUMINUM SUBSTRATE PCB

Home » Product » Aluminum PCB » ALUMINUM SUBSTRATE PCB

Aluminum PCB

ALUMINUM SUBSTRATE PCB

Base Material:FR4
Copper Thickness:1oz
Board thickness:1.6mm
Min. Hole Size:0.2mm
Min. Line Width:0.1mm
Surface Finishing:ENIG

Quote Now Next Product

Aluminum base PCB
1 Layer
Aluminum base PCB,Al 1.5mm,5052H34,dielectric 0.1mm,copper thickness 1 oz.
Solder mask white,silkscreen black.
Use in Led Lighting .

aluminum substrate pcb -detail

Metal Core PCB Capability:
Circuit Trace Width/Space: 4/4mil
The Minimum Hole Diameter: 0.5mm (NPTH), 0.3mm(PTH)
The Minimum legend Height/Width: 0.8mm/0.15mm
Surface Finishing: HASL-LF, ENIG, Immersion Silver,Plated Silver,OSP,ENEPIG
Maximum Panel Dimension: 1200mm x 600mm
Final Board Thickness: 0.5mm ~ 5.0mm
Final Copper Thickness: HOZ 1OZ 2OZ 3OZ 4OZ 6OZ 10OZ
Dielectric Thickness: 50um 75um 100um 125um 150um
Metal Type: AL(1100.3003.5052.6061),Mirror Finish Al, Cu, Fe,Stainless Steel
Metal Substrate Thickness: 0.5mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 3.0mm 3.2mm
Solder mask colour: White, Black, Green,Red, Yellow,Blue,Grey
Shaping: Tooling Punching,CNC Routing,V-CU
Special Hole: Blind&buried hole,Depth milling,T-slot,Countersink hole

Q:What is cctc-hfpcb.?
86PCB is a professional online PCB&PCBA order website, which can supply pcb&pcba, components purchasing-one stop service.

Q:What do your engineers do ? Can thay offer design or pcb layout ?
Yes, we offer. Our engineer team not only supply design service but also solve all kinds of problems for customers.

Q: If I don’t have gerber file, only schematic, can I get PCBs?
Yes, we can supply gerber file based on schematic and make PCB for you.

Q:How do you ship boards to my country or agent?
We ship PCB and PCBA to your country by sea shipping , or by air .

Q: Is it ok if I want some free samples?
Yes, we can supply you free samples if you have mass production order.

Q: What time can I contact you?
Our online working time is 7*24 hours.

Q: If I send you my design, how can you make sure that the design will not be known by others.
Bofore you send us the files about the project, in order to guarantee the safety of your design,We will sign NDA.

Q: What is the minimum order quantity if I want to order PCB ?
We don’t have MOQ.We accept any quantity even one piece.

Q: If I want to get quotation of Aluminum PCB, Metal Core PCB, LED PCB, what should I do?
You can kindly send us gerber file ,specifications of your requirement, we will quote immediately for you.
