Our services for you:
- 1 to 30-layer FR-4 PCBs with HDI and metal core PCBs such as aluminum based PCBs, copper based PCBs and iron based PCBs
- Production of prototypes, high-mix, medium or low
- Volume orders ith IPC standards
Metal core PCBw
Capability of PCB
Standard: advanced
Number of layers: 1-16/30
Base: Fr4, Cem1, high TG, AL base, PT, Rogers, Nalco
Base materials: FR4 tg/Tg>=130min/TG/>=170 max
Finish board thicknesses: 0.3-6.0mm/<0.30/>7.0mm
Minimum core thickness: 0.10cu (excluded cu)
Copper thickness:
Inner layer: 4oz (max)
Outer layer: 5oz (max)
Inner layer: 5oz (max)
Advantages:
▪No MOQ ; 18 years of PCB&PCBA turnkey services
▪Quick turn, Prototype, Low & medium & high volume
▪Components sourcing, ODM&OEM services provide
▪ISO 9001-, ISO 14001-, ISO/TS16949, ISO13485, IATF16949, OHSAS18001certified, UL E352816
▪100% E-test, visual, AOI inspection, including X-ray, 3D microscope and ICT
▪Fast response within 24 hours
Full Range Of Testing Services:
▪AOI, Function testing, In circuit testing, X-ray for BGA testing
▪3D paste thickness test
▪Flash testing and earth bonding tests can also be undertaken where required
Using our X-ray machine, we test PCBs to component level and all wiring is fully inspected and tested
Each board is carefully examined by our dedicated inspection team using AOI and high magnification viewers
FAQ:
For PCB order: provide gerber file and manufacturing specifications
For PCBA order: provide gerber file, manufacturing specification, BOM list and pick and place/XY file
Well-trained and experienced staffs to answer all your questions with fluent English
Protection of your sales area, ideas of design and all your private information
Any further question, welcome to contact us by sending inquiries.
